Hydro Beam X1 Technical Specifications
Voltage: 100V ~ 240V/50~60Hz
IP Rating: IP65
Lamp: Osram Sirius HRI 100W Discharge Lamp
Lamp Hours: 6,000 Hour Average Lamp Life*
Color Temperature: 9000K
Power Draw: 235W
Weight: 36 lbs./ 16.3 kgs.
Dimensions: 13.25” (L) x 8.25” (W) x 18.05” (H)
336 x 210 x 458mm
Gobos: 15 Gobos + Open
Prisms: 16 Facet Circular)
DMX Channels: 2 DMX Modes: 11 / 14
Warranty: 2 Year (730 days)
* May vary depending on several factors including but not limited to:
Enviromental Conditions, Power/Voltage, Usage Patterns (On-O Cycling), Control, and Dimming.
Please Note: Specications and improvements in the design of this unit and this
manual are subject to change.
ADJ Products, LLC - www.adj.com - Hydro Beam X1 User Manual Page 39
