32
INSTRUCTION MANUAL
ELECTRONIC PERSONAL SCALE
Your new personal scale has been designed to accurately indicate your weight gain or loss over a period of time and
should give many years of service under normal use.
SPECIFICATIONS
• high precision „Strain-Gauge” sensor
• FA-8013-3: 5 mm safe tempered glass platform
• Capacity: FA-8013-3: 150 kg
• Division: 100 g
• Tap to start
• Automatic zero resetting
• Automatic switch o
• Over load indicator
• Low battery indicator
POWER SUPPLY
1 pcs of lithium battery included (CR2032).
Please remove the insulation sheet from the battery contacts before use. Please take note to plolarity. Replace the
batteries when the scale shows „LO”.
OPERATION
1. Place the scale on a hard, at surface (avoid carpet or soft surface).
2. Gently step on the scale, then the scale will be automatically turned
on. Stand evently on the scale without moving and wait until your
weight shown on the display is stable and locked.
AUTOMATIC SWITCH OFF
When you step o the scale. it will automatically switch o.
Auto shut-o occurs if display shows „0.0“ or shows the same weight reading for approximate 8 seconds.
OVERLOAD INDICATOR
When the scale is overloaded (over 150 kg) the following will appear on the screen:
LOW BATTERY INDICATOR
When the batteries need replacing, the following will appear on the screen:
RE-TEST
Display „C“ when you step o the scale, means this weight reading with error. Please re-test.
INSTRUCTION OF LITHIUM BATTERY REPLACEMENT
Please open battery cover, then take the battery carefully out of the battery compartment, do not bend the electrode
back while you do this or they might be broken. Dispose of the old battery at the appropriate rubbish collection.
(Please select 1 or 2 according to the way of the battery installation)
1. (1) To take out the old battery: pull outwards the knob which is on the side or the battery slot gently and take
out the battery. (picture A)
(2) To replace a new one: put one edge of the new battery down under the electrode then pres down the other
edge inside the slot from the knob side. (picture B, picture C)
1. the knob 2. electrode
2. (1) Use a sharp driver to kick out the battery from the hole at the side of the battery slot. (picture A)
(2) Insert the edge of the new battery under the panel opposite to the hole and then press it down. (picture B
picture C)
3. Panel 4. Hole 5. Slot
CAUTION: To pull electrode sheet strongly may cause it broken or lose elasticity during the process of battery
replacement.
TO CONVERT WEIGHT UNIT
If the scale is with both measuring system of Metric (kilograms) and Imperial (pounds, stones),
you can convert weight unit as follow:
Condition 1: if the unit switch is inside battery case,
A. Open battery case cover on the back of scale.
B. Pull up and down the unit switch to convert scale unit between kg-lb-st.
Condition 2: if the unit switch is on the back of the scale,
A. Find unit switch on the back of scale.
B. Pull up and down the unit switch to convert scale unit between kg-lb-st.
Condition 3: if the unit switch is on the back of the scale,
A. Find unit switch on the back of scale.
B. Press the unit conversion button when scale is power on, LCD shows current weight unit.
Press the button again to convert weight unit.
ADVICE FOR USE & CARE
• The glass will be slippery when it is wet. Keep it dry!
• Keep standing still during the course of weighing.
• This product can only used by static pressure. Avoid breaking the glass by striking, shocking or dropping.
• Clean your scale with a damp cloth but avoid water getting inside the scale. Do not use chemical cleaning agents.
The sticking part of the glass to the metal should not be soaked by water.
• Keep your scale in a cool place with dry air instead of humid or hot places.
• Keep your scale in horizontal position instead of standing on side.
• This scale can only be used for weighing human body. Do not use it for commercial purpose.
• Treat your scale with care – it is a precision instrument. Do not drop it or jump on it.
• If failed to turn on the unit, check whether battery had been installed, or battery power too low. lnsert or replace
new batteries.
• If there are some error on the display or can not turn o for a long tirne, please take o the battery for about
3 seconds, then encase it again to remove the soft-fault. If your can‘t resolve the problem, please contact your
dealer for consultation.
• Do not use it for commercial purpose.
Environment friendly disposal
You can help protect the environment! Please remember to respect the local regulations: hand in the non-
working electrical equipments to an appropriate waste disposal center.
ENGLISH
ENGLISH
