ENGLISH

•

Do not repair the unit by yourself. Do not disassemble the

unit by yourself, if any malfunction is detected or after it

was dropped, unplug the unit and apply to any authorized

service center at the contact addresses given in the war-

ranty certificate and on the website www.coolfort.ru.

•

To avoid damages, transport the unit in the original

package only.

•

Before you dispose of the vacuum cleaner, remove the

battery and apply to the corresponding center for recy-

cling of it. Do not burn the vacuum cleaner even if it is

badly damaged without removing the battery to avoid

the battery explosion.

•

Transport the unit in the original packaging only.

•

Keep the unit in a dry cool place out of reach of children

and disabled persons.

THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY. ITS

COMMERCIAL USAGE AND USAGE IN PRODUCTION AREAS

AND WORK SPACES IS PROHIBITED.

FUNCTION CAPABILITIES

Control and navigation in the mobile app

Control the unit, set up the cleaning modes and monitor the

operation process with COOLFORT mobile app.

BEFORE THE FIRST USE

After unit transportation or storage under cold (winter)

conditions, it is necessary to keep it for at least three

hours at room temperature before switching on.

•

Unpack the vacuum cleaner and remove any advertising

stickers and package materials.

•

Keep the original package.

•

Check the unit for damages, do not use it in case of

damages.

•

Read the safety instructions and the operation manual.

•

Make sure that operating voltage of the power adapter

corresponds to the voltage of your mains.

REMOTE CONTROL

To use the remote control, open the battery compartment lid

and insert 2 «AAA» batteries strictly observing the polarity,

close the battery compartment lid.

If you do not use the unit for a long time, remove the batteries

from the battery compartment of the remote control.

Batteries leakage can cause injuries or damage the

unit. To avoid the unit damage, follow the instructions

given below:

–

use only the «AAA» batteries;

–

do not use old and new batteries at the same time or dif-

ferent types of batteries;

–

do not recharge the batteries;

–

insert the batteries strictly following the polarity;

–

remove the batteries if you are not planning to use the

unit for a long time;

–

apply to specialized centers for further recycling of the

batteries;

–

avoid the power nippers circuit.

VACUUM CLEANER ASSEMBLY

Removal-installation of side brushes (2, 5) (Fig. 1)

•

Turn the vacuum cleaner over and insert the side brush-

es (2, 5) until they click.

•

The left side brush (5) has a green center, the right brush

(2) has a red one.

Note:

1. The right and left side brushes are not interchangeable.

2. After every use clean the brushes from dust and

garbage and, if necessary, wash them under warm

water jet.

•

To remove the side brush (2, 5), take it by the two drive

tangs and pull it up.

Removal-installation of the container

for collecting garbage and dust (11)

•

Open the upper lid of the robot (12) and remove the con-

tainer by the handle (27).

•

Remove the filter holder (23) together with the HEPA

filter (24).

•

There is a corresponding groove in the lid of the con-

tainer (25) to remove the filter holder.

•

Pull the HEPA filter (24) by the flag and remove it from

the holder (23)

•

Press the container lid lock (26) and open the container

lid (25).

•

A fine mesh is integrated into the container lid to retain

garbage and large particles.

•

Pay attention to the dust-proof valve (28) located inside

the container (11).

•

The valve (28) prevents dust and garbage falling out

when removing the container from the vacuum cleaner.

•

The valve should open and close freely without any jam-

ming.

•

Close the lid (25) of the container (11) until it clicks.

•

Insert the HEPA filter (24) back into the holder (23).

•

Insert the filter holder (23) back into the lid of the con-

tainer (25).

•

Place the assembled container (11) back into the robot

body and close the lid (12).

Installation of the charging station (32)

•

Install the charging station on a flat floor surface, against

the wall, the base of the charging station should be per-

pendicular to the floor.

•

The free space in front of the charging station should

be at least 1.5 meters, the free distance from the sides

of the charging station should be at least 0.5 meters

(Fig. 2).

•

Insert the plug of the power supply connection cord

(36) into the socket (35) at the charging station (32).

Carefully wind up the power supply connection cord, do

not allow it to hang down (Fig. 2, 3).

Note: Do not install the charging station near objects with

high reflectivity, for example, near mirrors, otherwise it

will be difficult for the vacuum cleaner to find the charging

station.

Removal-installation of the water tank (21)

To remove the water tank, press the key (22) and pull it out

of the robot body.

To install, insert it back into the body until it clicks (Fig. 4).

Removal-installation of the accessory

for wet floor cleaning (9)

(Used only in conjunction with the water tank (21))

•

Install the microfiber cloth (29) on the wet floor clean-

ing attachment (30) as follows: hold the cloth (29) with

the smooth side up, and the attachment (30) with touch

fasteners down, then insert the attachment into the

pocket of the cloth, pull the cloth slightly in the middle,

straighten the fabric around the edges and fix it with the

touch fasteners.

•

Install the assembled wet cleaning accessory (9) on

the water tank (21), to do this, align the two holes on

the tank with the fasteners on the attachment (30), as

shown in the figure (Fig. 5) by two arrows, then press

the attachment until it clicks. To remove the accessory,

press the attachment (30) in the direction away from

the tank (21).
