00.11
Model C1
Connection
62 Instruments
Instrument cluster to instrument panel Nm 3
Cable clamp to instrument cluster Nm 1
Cable terminal to instrument cluster Nm 0.5
Model C1
Connection
63 Lights
Front/rear turn signal lens Nm 2
Front turn signal to fairing Nm 2
Rear turn signal to license plate holder Nm 3
Headlight subframe Nm 9
Taillamp cluster Nm 5
Model C1
Connection
65 Optional extras
Alarm system
Control unit Nm Hand-tight
Motion sensor Nm Hand-tight
Bracket/ignition coil Nm 5
Fun audio system
Volume control Nm Hand-tight
Amplifier Nm 2
Speaker front trim panel Nm 2
Speaker bracket Nm 4
Model C1
Connection
72 Seat belts
Seat belt inertia reel to frame Nm 42
Belt buckle to belt-buckle mount Nm 42
Belt-buckle mount to frame Nm 42
Secondary mudguard Nm 5
