Aerofit IT9306 [5/24] 页面 5

Превью страниц Страница 5 / 24

─ 5 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No.

Description Qty

Item No.

Description Qty

1 Weight Stack Frame 1 36 Lower Side Cover 1

2 Main Frame 1 37 Rear Support 1

3 Bottom Cross Brace 1 38 Top Rear Shroud A 1

4 Movement Arm 1 39 Top Front Shroud 1

5 Support Arm 1 40 Support 1

6 Pivot Arm 1 41 PlugΦ95.4*61 2

7 Cam 1 42 Plastic Block 12

8 Adjustable Handle 1 43 Side Cover 1

9 Adjustable tube 1 44 Guide Rod 2

10 Rear Cross Brace 1 45 4.5" Pulley 3

11 Back Pad Support 1 46 Aluminium Grip Cap 2

12 Swing Tube 1 47 Aluminium Grip ring 2

13 Main Bracket 1 48 Big Collar 2

14 Adjustable Foot plate 4 49 Collar Φ65.6*Φ50.5*12.7 1

15 Seat Pad Plate 1 50 Bumper Φ32*Φ25.4*40 1

16 Adjustable Support 1 51 Top Plate 1

17 Flat Washer Φ32*Φ26*5 1 52 Selector Pin W/Coil 1

18 Swing Tube Scaleboard 1 53 Plastic Tube Guide 2

19 Scaleboard R115*2 1 54 Plug RT50*100 5

20 Scaleboard R217.5*2 1 55 Plug Φ50.8 1

21 Flat Washer Φ40*Φ26*5.5 1 56 Grip 2

22 Pin Pole Φ10*566 1 57 Yellow Grip 1

23 Spacer Φ14*Φ10.5*15 1 58 Adjustable Support Sleeve 1

24 Cable 1 59 Button 19

25 Thigh Pad 1 61 Weight Rubber Bumper 2

26 Seat Pad 1 62 Front Shroud 1

27 Back Pad 1 63 Rear Shroud 1

28 Roller 1 64 Little BumperΦ17*10.5 6

29 Bearing Φ50.8*Φ25.4*15.9 8 65 Bushing Φ16*Φ12*8 2

30 Main Shaft Φ25*335.4 1 66 Bushing Φ38*Φ25.4*18 2

31 Flange 2 67 Plate 2

32 Counter Poise Block 1 68 Pin End Φ17.7*100 1

33 Pin 1 69 Pin Pole Φ10*637 1

34 Aluminum End Cap Φ50*Φ10.5*8 4 70 Ball 2

35 Upper Side Cover 1 71 Spring Φ1.2*Φ12.9*70 1
