─ 6 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No.

Description Qty

Item No.

Description Qty

72 Spring Φ1.2*Φ13*38.6 1 109 Nylon lock Nut M8 6

73 Arc Bracket 1 110 Nylon lock Nut M5 2

74 Socket Set Screw M8*8 4 111 Flat Washer Φ13*Φ24*1.5 11

75 Cover Φ14*Φ9.4*22 1 112 Flat Washer Φ11*Φ20*2 47

76 Short Shroud Retainer Plate 2 113 Flat Washer Φ9*Φ16*1.6 8

78 L Bracket 4 114 Flat Washer Φ5.5*Φ12*1 4

79 Retaining Snap Ring d=25 1 116 Hex Key S=3 1

80 Socket Head Cap Screw M4*15 1 117 Hex Key S=4 1

81 Hex Head Bolt M12*35 2 118 Hex Key S=5 1

82 Hex Head Bolt M12*85 2 119 Hex Key S=6 1

83 Hex Head Bolt M10*20 5 121 Hex Key S=3/32" 1

84 Hex Head Bolt M10*100 2 122 Wrench 1

85 Hex Head Bolt M10*80 4 123 Lube 1

87 Button Head Cap Screw M10*65 2 125 Weight Plate 5LBS 2

88 Hex Head Bolt M10*50 4 126 Weight Plate 10LBS 3

89 Hex Head Bolt M10*35 2 127 Weight Plate 15LBS 10

90 Hex Head Bolt M10*30 10 128 Plastic Cap Φ30 2

91 Hex Head Bolt M10*25 2 129 Washer Φ27.6*Φ12.8*3.5 2

92 Button Head Cap Screw M8*60 1 130 Nut 2

93 Button Head Cap Screw M8*55 1 131 Pin End Φ17.7*50 1

94 Flat Head Cap Screw M10*25 4 132 Spring Φ1.5*36 1

95 Flat Head Cap Screw M10*30 5 133 Plug 4

96 Flat Head Cap Screw M10*75 1 134 Connect Button 4

97 Socket Set Screw 10-32*6.4 2 135 Plastic Washer 4

98 Socket Head Cap Screw M8*30 1 136 Plastic Cover 4

99 Socket Head Cap Screw M8*15 2 137 Rubber Plug Φ29*Φ19*10 2

100 Socket Head Cap Screw M8*25 4 138 Hex Head Bolt M8*30 2

101 Socket Head Cap Screw M5*25 2 139 Spring Washer Φ8 2

102 Flat Philips Screw M5*25 2 140 Flat Washer Φ9*Φ22*1.6 2

103 Flat Philips Screw M5*16 19 141 Rivet Nut M8 2

104 Button Head Cap Screw M6*12 2 142 ButtonΦ8.1*7 10

105 Socket Set Screw 10-32*3.2 4 143 Screw ST4.2*10 4

106 Hex Nut M6 2 144 Shroud 1

107 Nylon lock Nut M12 7 145 Top Rear Shroud 1

108 Nylon lock Nut M10 16 146 Shroud Retainer Plate 4
