Group Sequences

● Local Monitor Seize

The system allows operators to start and control a group sequence in only local domains. Before starting a group

sequence operation, a local monitor must be seized. Be sure that the group sequence monitors are not seized by

operators with higher priority.

● Group Sequence Operation

Group Sequence operations include start, stop, pause, run, next step, and previous step. (Refer to p. 33.)

● Group Sequence Priority

If another operator with higher priority has seized a Group Sequence monitor, that monitor will maintain the original

operator priority.

Note:

 • GroupSequencemonitorsshouldbethesameineachstepofsequenceandlessthan33.

• During3secondsdwelltimeincaseofWJ-GXD400,thevideoandOSDdisplaywilldelayaccordingtoswitch-

ing channel numbers.

■

Alarm Programming and Handling

● Program the Alarm

This function allows administrators to program alarms, assign alarm display targets, and define alarm actions.

● Control Alarm

Alarm controls are operator functions. These functions allow the highest priority operator to seize the alarm and

control it. These functions also allow the next highest priority operator to gain control after the highest priority oper-

ator releases the alarm.

The alarm controls include:

 • Armanddisarmalarms

 • Acknowledgeactivealarms

 • Resetacknowledgedoractivealarms

The system also supports automatically resetting and acknowledging alarms through configuration by the Admin

Console.

● Alarm Action

The system supports the following alarm actions:

 • Cameraspots

 • Toursequences

 • Groupsequence

 • Textdisplay(Only WJ-SX650 or WJ-SX850 switch node)
