44
F3: Gen
Displays or hides the general status display.
F4: Mon
Displays or hides the moitor status display.
Note:
• Refertotheillustrationsinp.35 for each OSD
item.
• T&DandGenareavailableinonlyWJ-SX650or
WJ-SX850 switch node.
■
Digital Output
Note:
• ThisfunctionisavailableonlywhenDigitalOutput
setting has been established through the admin
console.(RefertotheAdminConsoleUser's
Guide.)
1. Display "DigiOut" menu. (Refer to Step 1 of p. 41
To Recall Menu Functions.)
2. Select a Digital Output number by pressing the
numeric buttons.
3. Press the F1 (Set) or CAM(SET) button. A one-shot
pulse will be produced, and an assigned event will
be activated.
Note:
• DigitalOutputdoesnotsupporttherestorefunc-
tion.
■
Alarm Status Table
The table shows the alarm statuses.
1. Select a desired monitor. (Refer to p. 27 Monitor
Selection.)
2. Display "AlmStat" menu. (Refer to Step 1 and 2 of
p. 41 To Recall Menu Functions.)
DigiOut: 007
Set
AlmStat: 008
On Off Blk
3. Select a desired function by pressing one of the F1
to F3 buttons.
Available buttons and functions
F1: On
Opens the ALARM STATUS table.
F2: Off
Closes the ALARM STATUS table.
F3: Blk
Changes the monitor background beween camera
images and black picture.
NAME: Alarm text
(Refer to p. 39 for other columns on the table.)
4. Todisplaythenextpage,pressthe+button.
Todisplaythepreviouspage,pressthe–button.
Note:
• Todisplaythefirstpageoftable,pressthe+but-
ton while holding down the SHIFT button.
• Todisplaythelastpageoftable,pressthe–button
while holding down the SHIFT button.
5. To exit the ALARM STATUS table, perform one of
the following.
• Selectacamera.(Refertop.27 Camera
Selection.)
• PressF2,thenpresstheMON(ESC)button.
• PressF2,thenpresstheEXITbutton.
Note:
• ThisfeatureisavailableinonlyWJ-SX650or
WJ-SX850 because of OSD limitation.
ALARM STATUS PG
ALM STATE NAME
1 DISARMED FRONT DOOR
1 ARMED BACK DOOR
1 ACTIVE –
1 ACKED –
1 CLEARED –
1 RESET –
