18
● Hard Disk Recorder WJ-HD316A Setup
Refer to WJ-HD316A Operational Manual to set following configuration.
DVR# Line Speed HTTP PORT DHCP IP Address Gateway Unit Address
(System)
Unit Address
(Controller)
1 AUTO 0080 OFF 172.18.0.60/16 0.0.0.0 001 001
● L3SW Setup
Set a restriction for the multicast message not to flow to Server PC port.
Valid the IGMP V2 due to support Multicast messages.
