26
Login and Logout
■
Operation Start (Login)
1. Turn on the power switches of all system compo-
nents.
2. Turn on the power of system controller.
The OPERATE indicator will light up, and the fol-
lowing message will appear on the LCD.
Note:
• Waitunitlthefollowingdisplayappearsonthe
LCD.
3. Enter the ID number by pressing the numeric but-
tons.
Then, press the CAM (SET) button. "PWD" will
appear on the LCD.
Note:
• WhenyouhaveenteredawrongIDnumber,press
the CLEAR button.
4. Enter the password by pressing the numeric
butons.
5. Press the CAM (SET) button.
When the password is correct, "OK" will apear for
2 seconds on the LCD.
Connecting to
Main CPU ...
ID:
Unit:01
ID:12345
PWD:
ID:12345
PWD:∗∗∗∗∗
MON PWD:OK CAM
Unit:01
Note:
• Whenthepasswordiswrong,"NG"willappearfor
2 seconds on the LCD. In this case, retry the login
procedure.
Note:
• Ifyouperformtheloginprocedureafterresetting
the CPU unit or turning on the power of CPU unit,
the LCD display may return to Step 2. In this case,
wait for approx. 5 minutes until the CPU unit has
been started up. Then, retry the login procedure.
■
Operation End (Logout)
You need to log out of the system:
• Whenleavingthecontroller
• Whensystemaccessisnolongerrequired
1. During the login status, press the MON LOCK/
LOGOUT button while holding down the SHIFT
button.
2. You will log out of the system, and the LCD display
will return to the login standby display.
■
ID Display Function
You can check the following on the LCD. (Refer to
p. 47 for how to display.)
• OperatorID
• ControllerID
• Systemversion
ID:12345
PWD:NG
ID:
Unit:01
