45
■
Video Loss Status Table
The table shows the video loss detection statuses.
1. Select a desired monitor. (Refer to p. 27 Monitor
Selection.)
2. Display "VL Stat" menu. (Refer to Step 1 and 2 of
p. 41 To Recall Menu Functions.)
3. Select a desired function by pressing one of the F1
to F3 buttons.
Available buttons and functions
F1: On
Opens the VIDEO LOSS STATUS table.
F2: Off
Closes the VIDEO LOSS STATUS table.
F3: Blk
Changes the monitor background beween camera
images and black picture.
CAM: Logical camera number
PORT#: Video input port number
NODE: Video switch node type
STATUS:
ABV/IN: Video level is above normal and in
sync.
BLW/IN: Video level is below normal and in
sync.
ABV/OUT: Video level is above normal and out
of sync.
BLW/OUT: Video level is below normal and out
of sync.
LOCATION: Logical cage number that the port
belongs to.
VL Stat: 009
On Off Blk
VIDEO LOSS STATUS PG
CAM PORT NODE STATUS LOCATION
6400 999 SX ABV/IN 1234567890
6400 999 SX ABV/OUT 1234567890
6400 999 SX BLW/IN 1234567890
6400 999 SX BLW/OUT 1234567890
4. Todisplaythenextpage,pressthe+button.
Todisplaythepreviouspage,pressthe–button.
Note:
• Todisplaythefirstpageoftable,pressthe+but-
ton while holding down the SHIFT button.
• Todisplaythelastpageoftable,pressthe–button
while holding down the SHIFT button.
5. To exit the VIDEO LOSS table, perform either of
the following.
• Selectacamera.(Refertop.27 Camera
Selection.)
• PressF2,thenpresstheMON(ESC)button.
• PressF2,thenpresstheEXITbutton.
Note:
• ThisfeatureisavailableinonlyWJ-SX650or
WJ-SX850 because of OSD limitation.
■
System Status Table
The table shows the system status in real time.
1. Select a desired monitor. (Refer to p. 27 Monitor
Selection.)
2. Display "SysStat" menu. (Refer to Step 1 and 2 of
p. 41 To Recall Menu Functions.)
3. Select a desired function by pressing one of the F1
to F3 buttons.
Available buttons and functions
F1: On
Opens the SYSTEM STATUS table.
F2: Off
Closes the SYSTEM STATUS table.
F3: Blk
Changes the monitor background beween camera
images and black picture.
SysStat: 010
On Off Blk
