Menu Function Descriptions
■
Menu Functions
No. Function
001 Camera Setup
002 Auto Mode
003 BW Mode
004 Patrol Control
005 Group Preset
006 OSD Control
007 Digital Output
008 Alarm Status
009 Video Loss Status
010 System Status
011 Video Loss History
012 Area Change
013 Operator ID
014 Controller ID
015 System Version
■
To Recall Menu Functions
1. Press the MENU button. "CamMenu" menu will
appear on the LCD.
2. Press the MENU button repeatedly until a desired
menu appears. (Refer to pages
42
to
47
.)
Note:
• WhenyoupresstheMENUbuttonrepeatedlywhile
holding down the SHIFT button, each menu will
appear in the reverse order.
• Youcanalsoselectthemenubyrotatingthe
JogDial clockwise or counterclockwise.
3. Perform the operations to activate the selected
function. The operating procedure differs depend-
ing on each function. (Refer to pages
42
to
47
.)
CamMenu: 001
On
5
Off Rst A.Rst
4. To exit the menu, press the EXIT or MON (ESC)
button. The LCD display will return to the default
status.
