27
After the login procedure, the following operations are
available to control the system.
The operation begins with monitor selection. Then, the
image of selected camera appears on the active moni-
tor.
■
Monitor Selection
1. Select the desired monitor number by pressing the
numeric buttons. The entered number will appear
on the LCD.
2. Press the MON (ESC) button.
When the selected monitor number is correct, <" is
displayed.
Note:
• Toselectthenextorpreviousmonitornumber,
pressthe+or–button.
■
Camera Selection
1. Select the desired camera number by pressing the
numeric buttons. The entered number will appear
on the LCD.
2. Press the CAM (SET) button.
When the selected camera number is correct, >" is
displayed.
Note:
• Toselectthenextorpreviouscameranumber,
pressthe+or–button.
MON 123 CAM
Unit:01
MON CAM
0123<Unit:01
MON 512 CAM
0123<Unit:01
MON CAM
0123 Unit:01 >00512
Monitor Selection and Camera Selection
■
Monitor Lock
Monitorlockisthefunctiontoretainotheroperators'
control of a monitor even after that operator has
selected another monitor.
Note:
• Thisfunctionwillpreventoperatorswithalower
priority from gaining control of a monitor. However,
operators with a higher priority can gain the control
of monitor.
1. Select a desired monitor. (Refer to Monitor
Selection.)
2. Press the MON LOCK/LOGOUT button. The moni-
tor lock mode is activated, the monitor number
with "L" sign is displayed on the active monitor,
and "L" will appear beside "MON" on the LCD.
Note:
• EverytimeyoupresstheMONLOCK/LOGOUT
button, the monitor lock mode will be activated or
deactivated.
LMON CAM
0123 Unit:01 00512
