The system supports up to 10 alarm actions, and allows operators to control acknowledged alarm actions.

Note:

 • Thesystemcanhandleupto64alarmsatthesametime.Incaseofmorethan64alarms,somedelayhappens

before alarm actions.

■

Alarm Export to other Domains

● Alarm Export Function

This function allows a local alarm to export to another system domain.

● Assign Alarm Export in WV-ASC970 Admin

In the WV-ASC970 Admin Components screen, select the Alarm Export tab. From there, you can edit an alarm to

be exported to multiple system domains (units). The alarm ID has the following format:

Unit(Domain)id(2)+Alarmid(1).E.g.20001

In the above format, the domain ID has up to 2 digits and its range is from 1 … 64. The domain ID here is also

called alarm source domain, which means that the alarm originates from that domain.

● Setup an Exported Alarm as Global Alarm source in WV-ASC970 Admin Console

After creating an alarm to be exported to a destination domain, an administrator must enter the alarm information

into the destination domain alarm database using its WV-ASC970 Admin Console.

In the WV-ASC970 Admin Console main menu, select Records from the Alarm command on the Components

menu. For alarm Source, select the source type Global Alarm and ID to 20001 (in the above case).

■

Event Operation

The function allows administrators to program system events. The event function currently supports following oper-

ations:

 • Cameraspot

 • Toursequence

 • GroupPreset

 • GroupSequence

 • Armanddisarmalarm

 • Upto4systemmodes

■

Digital Input and Output Functions

This function allows operators to select and set digital output ports. The system alarm function can program the

digital output ports as part of the alarm state change indication. The system alarm function can also program the

digital input ports as alarm trigger sources.
