46
SYSTEM STATUS PG
MON -A- CAM/DVR/SEQ DEV USER PRI
1 1 C6400001 K1 1 1
999 999 R6400001 S128 12345 1234
999 999 T640010001P S128 12345 999
999 999 G640010001P S128 12345 999
MON: Monitor number
AREA: Area number
CAM/DVR/SEQ:
<Example>
C6400001: Unit 64, Camera 1
R6400001: Unit 64, Recorder 1
T640010001P: Unit 64, Area 1, Tour Sequence
1 pause
G640010001P: Unit 64, Area 1, Group
Sequence 1 pause
DEV: Device Name
K: System controller number with normal user
operator.
S: System controller number with super user
operator.
ALM: Alarm
EVT: Timer event
USER: User ID
Note: Alarm USRID consists of alarm number
and alarm action number.
E.g."ALM20"indicatesalarm#2andits
action#0.
PRI: User priority
4. Todisplaythenextpage,pressthe+button.
Todisplaythepreviouspage,pressthe–button.
Note:
• Todisplaythefirstpageoftable,pressthe+but-
ton while holding down the SHIFT button.
• Todisplaythelastpageoftable,pressthe–button
while holding down the SHIFT button.
• IftheDVRisanetworkdiskrecorder,R6400001
indicates the camera number related to the record-
er.
• ThePRIfieldindicates"–"whenthepriorityisset
to "0".
5. To exit the SYSTEM STATUS table, perform either
of the following.
• Selectacamera.(Refertop.27 Camera
Selection.)
• PresstheMON(ESC)button.
• PresstheEXITbutton.
Note:
• ThisfeatureisavailableinonlyWJ-SX650or
WJ-SX850 because of OSD limitation.
■
Video Loss History Table
There are 100 video loss detection records stored in
chronological order in 10 pages of table.
1. Select a desired monitor. (Refer to p. 27 Monitor
Selection.)
2. Display "VL Hist" menu. (Refer to Step 1 and 2 of
p. 41 To Recall Menu Functions.)
3. Select a desired function by pressing one of the F1
to F3 buttons.
Available buttons and functions
F1: On
Opens the VIDEO LOSS HISTORY table.
F2: Off
Closes the VIDEO LOSS HISTORY table.
F3: Blk
Changes the monitor background beween camera
images and black picture.
CAM: Logical camera number that is connected to
the system.
STATE: Indicates video loss changes.
OK: Video loss is recovered.
LS: Video level is below normal and in sync.
VL: Video level is below normal and out of
sync.
VL Hist: 011
On Off Blk
VIDEO LOSS HISTORY PG
CAM STATE TYPE DATE/TIME
6401 OK C 01/01/01 12:00
