GB
19
PM66CEE04 RANGE COOKERS
Knob position Type of cooking
1 – 2 Maintaining the set temperature (Bechamel Sauce)
2 – 3 Warming up dishes
3 – 4 Pasta, vegetable soup, stew, ragu
4 – 5 Cooking, meat stew
5 – 6 Steamed vegetables, beef steak,  sh
6 Grilled meals, fried eggs, lamb steaks
A titolo orientativo si può consultare il seguente quadro ricordandosi tuttavia che si
possono avere variazioni dovute alla qualità ed alla quantità delle vivande messe a
cuocere e al qusto di ciascuno.
PM66CEE04 RANGE COOKERS
• WARNING!
• Don’t look at the Halogen plates when they are in use – the light can be
harmful to the eyes.
• The ceramic glass surface is very sturdy, but a very strong hit with a solid
and heavy object can still damage it.
• If any damage occurs, if you  nd thin or thick cracks on the ceramic glass
surface, it is recommended that you do not use the cooker and contact the
technical support service.
• Do not put aluminium foil or plastic containers on heated surfaces.
• During its  rst days of use, the surface can produce a burning smell which
will eventually disappear.
BE CAREFUL!
Children, because of their height, may not see the remaining heat
indicator. This is why it is necessary to make sure that they don’t touch
electrical heating areas even when the heaters are switched o .
DIGITAL DISPLAY WITH TOUCH CONTROL
1. An automatic programme is in use (in some models you will see an
inscription “Auto” instead of the letter A).
2. Manual control setting.
3. This indicator  ashes when the timer is being set up
4. This indicator shows when a timer is activated.
5. A button used to decrease the time when a timer is being set. It is also
used to choose an audio signal level (three levels are available).
6. Setting selection button.
7. Button used to increase the time, when a timer is set.
• SETTING THE CLOCK
The  rst time you switch the appliance on, as well as after a power cut, the digits
and the indicator A on the display will  icker, and the cooker will not operate in this
position.
1. After switching on the cooker, press the button and hold for at least 2
seconds, until the symbol disappears. A  ashing
• symbol will appear
on the display..
2. Using the - and + buttons, set the time.
3. A few seconds after the last depression of the buttons, the chosen time
will be automatically saved.
• MANUAL MODE
The oven will operate in a manual mode (without a set cooking stop-time or set
cooking period) only when this symbol is seen on the display:
.
• TIMER
The timer produces an audio signal when the set time is up without switching o the
cooker. The maximum interval that can be set on a timer is 23 hours and 59 minutes.
When the set time runs out, the symbol
will disappear from the display, and the
signal will sound. The audio signal will automatically stop in 7 minutes, or you can
stop it by pressing any button on the display.
To set up the timer, please do the following:
1. Press the button and hold for at least 2 seconds, until a  ashing
symbol appears on the display.
2. Using the - and + buttons, set the required interval.
3. A few seconds after the last depression of the buttons, the timer will save
the required time and will start the count-down time.
• SEMIAUTOMATIC SETTIME COOKING
1. Set the required oven setting and the cooking temperature.
2. Press the button and hold for at least 2 seconds, until a  ashing
symbol appears on the display.
3. Release the button and press it again. A  ashing symbol will
appear on the display as well as the sign “dur” , which will eventually
be replaced by 0:00.
4. Using the
- and + buttons, set the required cooking time (the maximum
allowed is 10 hours).
5. A few seconds after the last depression of the buttons, the time will be
saved and the count-down will start. The symbols A and will appear
on the display. To show the current time on the display, press the M
button several times.
When the set time is up, a signal will sound, and the oven will automatically switch-
o . The audio signal will automatically switch o in 7 minutes, or you can stop it by
pressing any button on the display.
• SEMIAUTOMATIC SET STOPTIME COOKING
1. Set the required oven setting and the cooking temperature.
2. Press the button and hold for at least 2 seconds, until a  ashing
symbol appears on the display.
3. Release the button and press it again. A  ashing symbol will
appear on the display as well as the sign “dur” , which will eventually
be replaced by 0:00.
4. Press the M button once more. You will see the inscription “end” on the
display, which will eventually change to 0:00.
5. Using the
- and + buttons, set the required cooking time.
6. A few seconds after the last depression of the buttons, the time will be
saved and the count-down will start. The symbols A and
will appear
on the display. To show the current time on the display, press the M
button several times.
When the set time expires, an audio signal will sound, and the oven will automatically
switch o . The audio signal will automatically switch o in 7 minutes, or you can stop
it, by using any button on the display.
ATTENTION!
PM66CEE04 range cookers are equipped with an electrical multi-
functional oven with an in-built fan and an electrical grill. Information on
how to use them can be found in the next chapters of this manual.
