VA-1USB-T/VA-1USB-R - Connecting the VA-1USB-T and VA-1USB-R

To connect the VA-1USB-T and the VA-1USB-R as illustrated in the example

in Figure 5:

1. On the VA-1USB-T, connect:

 The USB host, (for example, a computer) to the USB Host Input

connector

 The RS-232 controller, (for example, a laptop controller with an

RS-232 interface) to the RS-232 9-pin D-sub connector

 An IR blaster to the IR 3.5mm mini jack

2. On the VA-1USB-R, connect:

 The first USB Devices port to a USB hard drive

 The second USB Devices port to a multimedia player

 The fourth USB Devices port to a USB flash storage device

3. Using STP cabling, connect the CAT 5/6 Out RJ-45 connector on the

VA-1USB-T to the CAT 5/6 In RJ-45 connector on the VA-1USB-R (see

Section 2.4).

4. Set the machine ID on both devices to the same ID using the Machine ID

DIP-switch (see Section 5.2).

5. Connect the power adapters to the power sockets on the VA-1USB-T and

VA-1USB-R, and plug the adapters into the mains electricity (not shown in

Figure 5).

6. Establish a TP link by pressing the Link button on the receiver.
