VA-1USB-T/VA-1USB-R - Getting Started
3
3
2.2 Safety Instructions
Caution:
No operator serviceable parts inside the unit
Warning:
Use only the Kramer Electronics power supply that is
provided with the unit
Warning:
Disconnect the power and unplug the unit from the wall
before installing
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
aims to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country
go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
2.4 Shielded Twisted Pair/Unshielded Twisted Pair
We recommend that you use Shielded Twisted Pair (STP) cable and stress that
the compliance to electromagnetic interference was tested using STP cable.
There are different levels of STP cable available and we advise you to use the
best quality STP cable that you can afford.
For the VA-1USB-T and VA-1USB-R pair we recommend the use of shielded,
twisted pair (STP), non-skew-free Kramer BC-STP cable.
!
