20
VA-1USB-T/VA-1USB-R - Default Communication Parameters
9 Default Communication Parameters
RS-232
VA-1USB-T
VA-1USB-R
Baud Rate:
115200
Data Bits:
8
Stop Bits:
1
Parity:
None
Ethernet
IP Address:
192.168.1.39
192.168.1.40
Network Mask:
255.255.255.0
Default Gateway:
192.168.1.1
