VA-1USB-T/VA-1USB-R - Technical Specifications
19
19
8 Technical Specifications
VA-1USB-T
VA-1USB-R
INPUTS:
1 USB host on a USB Type B
connector
1 Bidirectional RS-232 serial port
on a 9-pin D-sub connector (F)
1 TP CAT 5/6 IN on an RJ-45
connector
1 IR sensor
OUTPUTS:
1 TP CAT 5/6 OUT on an RJ-45
connector
1 Unidirectional IR port on a
3.5mm mini jack
4 USB devices on USB Type A
connectors
1 Bidirectional RS-232 serial port on
a 9-pin D-sub connector (F)
USB SUPPORT:
1.1 and 2.0 (bulk mode, not isochronous)
ETHERNET SPEED:
100/1000Mbps automatic selection
RS-232:
BAUD RATE:
Up to 115200bps
MODE:
Full-duplex
POWER
CONSUMPTION:
5V DC 800mA
5V DC 2.8A
MAXIMUM POWER
OUTPUT:
5V 500mA per USB port
TRANSMISSION
DISTANCE:
Up to 100m (328ft)
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE
TEMPERATURE:
–40° to +70°C (–40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12.1cm x 7.18cm x 2.42cm (4.76" x 2.83" x 0.95"), W, D, H
WEIGHT:
0.44kg (0.97lbs.) approx. each
INCLUDED
ACCESSORIES:
2 Power supplies
OPTIONS:
RK-T2B 19” rack adapter
