ASUS RS520-E8-RS8, RS520-E8-RS12-E
1-5
*Specifications are subject to change without notice.
Model Name
RS520-E8-RS12-E RS520-E8-RS8
Networking
LAN
2 x Intel
®
I210T + 1 x Management LAN
1 x Mezzanine 10G dual port LAN card
Graphic
VGA
Aspeed AST2400 32MB
Onboard I/O Connectors / LED
indicators
2 x RJ-45 GbE port
1 x RJ-45 management port
2 x USB 3.0 ports
1 x VGA port
1 x PS/2 keyboard/mouse combo port
OS Support
Windows
®
Server 2012 R2
Windows
®
Server 2012
Windows
®
Server 2008 R2
RedHat
®
Enterprise Linux
CentOS
Unbuntu
VMWare
Citrix XenServer
* Support versions are subject to change without notice. Refer to
www.asus.com for updates.
Management
Solution
Software
ASWM Enterprise
Out of Band
Remote
Management
ASMB8-iKVM for KVM-over-Internet
Dimension (HH x WW x DD)
615 mm x 444 mm x 88 mm
Net Weight Kg
(CPU, DRAM & HDD not
included)
23 Kg
Power Supply
1+1 renundant 770W 80PLUS Gold Power Supply
Power Rating
100-127/200-240VAC, 10A/5A, 50-60Hz, Class I
Environment
Operating temperature: 10
°
C – 35
°
C
Non operation temperature: -40
°
C – 70
°
C
Non operation humidity: 20% – 90% (Non condensing)
