ASUS RS520-E8-RS8, RS520-E8-RS12-E
1-9
1.6 Internal features
The barebone server includes the basic components as shown.
1. Redundant power supply
2. Power supply fan
3. ASUS Z10PR-D16 Server Board
4. SATA/SAS back panel
5. Slim optical drive (optional)
6. System fans
7. Asset Tag
8. Hot-swap 3.5-inch HDD Bay
RS520-E8-RS8
1
2
3
4
5
6 66 6
7
8
The barebone server does not include a oppy disk drive drive. Connect a USB oppy disk
drive to any of the USB ports on the front or rear panel if you need to use a oppy disk.
*WARNING
HAZARDOUS MOVING PARTS
KEEP FINGERS AND OTHER BODY PARTS AWAY
Turn off the system power and detach the power supply before removing or replacing any
system component.
