ASUS RS520-E8-RS8, RS520-E8-RS12-E
1-7
1.5 Rear panel features
The rear panel includes the expansion slots, system power sockets, and rear fans. The I/O
shields with openings for the rear panel connectors on the motherboard are also placed in the
real panel.
* This port is for ASUS ASMB8-iKVM controller and for techincians only.
RS520-E8-RS8
RS520-E8-RS12-E
1234
Redundant power supply
PS/2 keyboard/mouse cpmbo port
Power connector
LAN port 2
Serial port (optional)
LAN port 1
2 x USB 3.0 ports
DM management LAN port*
Mezzanine 10G dual-port LAN card (optional)
Redundant power supply
PS/2 keyboard/mouse cpmbo port
Power connector
LAN port 1
LAN port 2
2 x USB 3.0 ports
DM management LAN port*
VGA port
VGA port
Mezzanine 10G dual-port LAN card (optional)
Serial port (optional)
2.5-inch SSD Bay 1
2.5-inch SSD Bay 2
