Chapter 2: Hardware setup
2-22
2.7 SATA/SAS backplane cabling
connect to the 8-pin
power connector
connect to the slots
on the motherboard
SGPIO_SEL jumper:
[2-3] (default)
internal SGPIO2/3: connect to the
SGPIO2/3 to support PIKE card
and SAS RAID, support Intel
®
RSTe
and LSI
®
Mega RAID
J1: connect to the
power connector of
slim optical drive
RS520-E8-RS8
