Foxconn nt-ibt29-0h0wbae [11/55] Introduction
![Foxconn nt-ibt18-0h0wbae [11/55] Introduction](/views2/1167518/page11/bgb.png)
5
INTRODUCTION
1
COM
COM port
Use this port for devices such as Point Of Sales.
Connect Point Of Sales that uses Mini COM to COM cable to this port.
2
USB 2.0 port
This USB port supports the USB 2.0/1.0 specication. Use this port for USB
devices such as keyboard, mouse, USB printer, USB ash drives and hard
disk drives, etc.
3
VGA
VGA Port
Connect VGA-compatible displays such as a monitor or projector.
4
HDMI
HDMI port
The HDMI (High-Denition Multimedia Interface) port supports Full-HD
display devices.
Connect monitor or TV that uses HDMI connector to this port.
5 Kensington lock
Attach a Kensington security system or a compatible security lock to secure
your NanoPC in place.
6
RJ-45 LAN port
Supports 10/100/1000Mb/s Ethernet network.
Connect network cable to access Internet.
7
Line out
Connects to powered analog speakers or recording devices with optical
connectors (3.5mm jack).
8
Power input port
Connect power cord that come with your product.
