Foxconn nt-ibt29-0h0wbae [17/55] Connect usb devices
![Foxconn nt-ibt18-0h0wbae [17/55] Connect usb devices](/views2/1167518/page17/bg11.png)
11
PLACEMENT AND CONNECTING
Connect USB devices
Connect USB devices to the USB ports, for example, mouse, keyboard devices.
Connect network cable
Connect one end of a network cable to the RJ-45 LAN port, and the other end to a hub or
switch.
