27
BIOS SETUP
Onboard Device Conguration
► Onboard LAN Controller
This item is used to enable or disable the onboard LAN controller
► Onboard USB Controller
This item is used to enable or disable the onboard USB controller.
► Legacy USB Support
This item is used to enable the support for USB devices on legacy OS. If you have a USB keyboard or
mouse, set to enabled.
[Enabled]: This option will enable the legacy USB support.
[Disabled]: This option will keep USB devices available only for EFI applications.
► USB3.0 Support
This item is used to enable or disable USB3.0(XHCI) Controller Support.
► Azalia HD Audio controller
This item is used to enable or disable the Azalia HD Audio Controller.
Main Advanced Boot Power Health Security Save&ExitF-center
→ ←: Select Screen
↑ ↓/Click: Select Item
Enter/Dbl Click: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Onboard Device Configuration
Onboard LAN Controller [Enabled]
Onboard USB Controller [Enabled]
Legacy USB Support [Enabled]
USB3.0 Support [Enabled]
Azalia HD Audio controller [Enabled]
Enabled/Disabled
On-
board LAN Control-
ler
