Foxconn nt-ibt29-0h0wbae [18/55] Connect power cord
![Foxconn nt-ibt19-0h0wbae [18/55] Connect power cord](/views2/1167518/page18/bg12.png)
12
PLACEMENT AND CONNECTING
Connect power cord
Connect the power adapter to the power input port of the NanoPC, and then press the power button to
start it.
The power adapter is dissipating heat during normal use, please do not cover it and
keep it away from your body to prevent injury from heat exposure.
C
AUTIO
N
1
2
3
