16
BIOS SETUP
if you have more memory or I/O cards installed. It means, if your system loading is heavy, set to
optimal default may sometimes come out an unstable system. What you need now is to adjust BIOS
setting one by one, trial and error, to nd out the best setting for your current system. You also can
save or discard the changes and exit BIOS setup here.
