Component identification 12
Systems Insight Display
LED and color
Health LED
System power
LED
Status
Over temp (amber) Amber Green
The Health Driver has detected a cautionary
temperature level.
Over temp (amber) Red Amber
The server has detected a hardware critical
temperature level.
PCI riser (amber) Red Green The PCI riser cage is not seated properly.
Fan (amber) Amber Green One fan has failed or has been removed.
Fan (amber) Red Green
Two or more fans have failed or been
removed.
Power supply (amber) Red Amber
One or more of the following conditions
may exist:
•
Only one power supply is installed and
that power supply is in standby.
•
Power supply fault
•
System board fault
Power supply (amber) Amber Green
One or more of the following conditions
may exist:
•
Redundant power supply is installed and
only one power supply is functional.
•
AC power cord is not plugged into
redundant power supply.
•
Redundant power supply fault
•
Power supply mismatch at POST or
power supply mismatch through hot-plug
addition
Power cap (off) — Amber Standby
Power cap (green) — Flashing green Waiting for power
Power cap (green) — Green Power is available.
Power cap (flashing
amber)
— Amber Power is not available.
IMPORTANT: If more than one DIMM slot LED is illuminated, further troubleshooting is
required. Test each bank of DIMMs by removing all other DIMMs. Isolate the failed DIMM by
replacing each DIMM in a bank with a known working DIMM.
