Chapter 1: Introduction
1-7
• One PCI-X 133MHz slots (Slot1)
• One PCI-U (UIO) Slot (Slot0)
• SEPC (Supermicro PCI-E Power Connector) Slot (J11)
• One SIMLP IPMI Slot
BIOS
• 32 Mb AMI SPI Flash ROM
• PCI 2.2, ACPI 1.0/2.0/3.0, Plug and Play (PnP), DMI 2.3, USB Keyboard sup-
port, and SMBIOS 2.3
PC Health Monitoring
• Onboard voltage monitors for CPU1 Vcore, CPU2 Vcore, +5Vin, +12V, -12V
3.3Vcc (V), and Battery Voltage
• Fan status monitor with rmware control
• CPU/chassis temperature monitors
• Platform Environment Control Interface (PECI) ready
• Thermal Monitor 2 (TM2) support
• CPU fan auto-off in sleep mode
• CPU slow-down on temperature overheat
• Pulse Width Modulation (PWM) Fan Control
• CPU thermal trip support for processor protection, power LED
• Power-up mode control for recovery from AC power loss
• Auto-switching voltage regulator for CPU cores
• System overheat/Fan Fail LED Indicator and control
• Chassis intrusion detection
• System resource alert via Supero Doctor III
ACPI Features
• Slow blinking LED for suspend state indicator
• Main switch override mechanism
• ACPI Power Management
Onboard I/O
• Intel ICH10R supports six SATA2 ports (with RAID0, RAID1, RAID10, RAID5
supported in the Windows OS Environment)
• One SIMLP IPMI socket
• Intel 82576 dual-LAN Gigabit Ethernet controller supports dual Giga-bit LAN
ports
• One EIDE Ultra DMA/100 bus master interface
• One oppy port interface
