Chapter 2: Installation

2-13

X8DTN+

2-5 Control Panel Connectors/IO Ports

The I/O ports are color coded in conformance with the PC 99 specication. See

the picture below for the colors and locations of the various I/O ports.

1. Back Panel Connectors/IO Ports

BackPanelI/OPortLocationsandDenitions

Back Panel Connectors

1. Keyboard (Purple)

2. PS/2 Mouse (Green)

3. Back Panel USB Port 0

4. Back Panel USB Port 1

5. COM Port 1 (Turquoise)

6. VGA (Blue)

7. Gigabit LAN 1

8. Gigabit LAN 2
