Supermicro X8DTN+ [42/99] Frontcontrolpanelpindefinitions

2-20

X8DTN+/X8DTN+-LR User's Manual

X8DTN+

Power LED

The Power LED connection is

located on pins 15 and 16 of JF1.

Refer to the table on the right for

pin denitions.

NMI Button

The non-maskable interrupt button

header is located on pins 19 and 20

of JF1. Refer to the table on the right

for pin denitions.

Power Button

OH/Fan Fail LED

NIC1 LED

Reset Button

HDD LED

Power LED

Reset

PWR

Vcc

Ground

1920

Vcc

Ground

NMI

Vcc

PWR Fail LED

NIC2 LED

NMI Button

PinDenitions(JF1)

Pin# Denition

19 Control

20 Ground

Power LED

PinDenitions(JF1)

Pin# Denition

15 +5V

16 Ground

4.FrontControlPanelPinDenitions

A. NMI

B. PWR LED
