Chapter 4: AMI BIOS

4-13

RAS Sticky Error Handling

This option allows the user to decide how to handle Sticky RAS errors. The options

are Clear Errors and Leave Errors (unchanged).

VGA 16-Bit Decode

Select Enabled to enable the function of decoding VGA for the devices installed

behind the PXH PCI Controller Hub. The options are Enabled and Disabled.

IDE/SATAConguration

When this submenu is selected, the AMI BIOS automatically detects the presence

of the IDE devices and displays the following items.

SATA#1Conguration

If Compatible is selected, it sets SATA#1 to legacy compatibility mode, while se-

lecting Enhanced sets SATA#1 to native SATA mode. The options are Disabled,

Compatible and Enhanced.

CongureSATA#1as

This feature allows the user to select the drive type for SATA#1. The options are

IDE, RAID and AHCI. (When the option-RAID is selected, the item-ICH RAID

Code Base will appear.)

ICH RAID Code Base (This feature is available when the option-RAID is

selected)

Select Intel to enable Intel's SATA RAID rmware to congure Intel's SATA RAID

settings. Select Adaptec to enable Adaptec's SATA RAID rmware to congure

Adaptec's SATA RAID settings. The options are Intel and Adaptec.

SATA#2Conguration(Thisfeatureisavailablewhentheoption-IDEis

selected)

Selecting Enhanced will set SATA#2 to native SATA mode. The options are Disabled,

and Enhanced.

Primary IDE Master/Slave, Secondary IDE Master/Slave, Third IDE Master,

and Fourth IDE Master

Use these items to set the parameters of Primary IDE Master/Slave, Secondary

IDE Master/Slave, Third and Fourth IDE Master slots. Press <Enter> to activate the

following sub-items. Set the correct congurations accordingly.

Type

Select the type of device connected to the system. The options are Not Installed,

Auto, CD/DVD and ARMD.
