Chapter 1: Introduction

1-11

1-2 Processor and Chipset Overview

Built upon the functionality and the capability of the 5500/5600 Series Processor

platform, the X8DTN+/X8DTN+-LR motherboard provides the performance and

feature set required for dual-processor-based high-end systems with conguration

optimized for intensive application and high-end server platforms. The 5500/5600

Series Processor platform consists of the 5500/5600 Series (LGA 1366) pro-

cessor, the 5520 (North Bridge), and the ICH10R (South Bridge). With the Intel

QuickPath Interconnect (QPI) controller built in, the 5500/5600 Series Processor

platform is the rst dual-processing platform to offer the next generation point-

to-point system interconnect interface that replaces the current Front Side Bus

Technology and substantially enhances system performance by utilizing serial link

interconnections, allowing for increased bandwidth and scalability.

The 5520 connects to each processor through an independent QuickPath Inter-

connect link. Each link consists of 20 pairs of uni-directional differential lanes for

transmission and receiving in addition to a differential forwarded clock. A full-width

QPI link pair provides 84 signals. Each processor supports two QuickPath link,

one going to the other processor and the other to the 5520.

The 5520 supports up to 36 PCI Express Gen2 lanes, peer-to-peer read and write

transactions. The ICH10R supports up to 6 PCI-Express ports, six SATA ports

and 10 USB connections.

In addition, the 5500/5600 Series Processor platform also offers a wide range of

RAS (Reliability, Availability and Serviceability) features. These features include

memory interface ECC, x4/x8 Single Device Data Correction (SDDC), Cyclic Re-

dundancy Check (CRC), parity protection, out-of-band register access via SMBus,

memory mirroring, and Hot-plug support on the PCI-Express Interface.

The Main Features of the 5500/5600 Series Processor and

the 5520 Chipset

•Four processor cores in each processor with 8MB shared cache among cores

•Two full-width Intel QuickPath interconnect links, up to 6.4 GT/s of data transfer

rate in each direction

•Virtualization Technology, Integrated Management Engine supported

•Point-to-point cache coherent interconnect, Fast/narrow unidirectional links, and

Concurrent bi-directional trafc

•Error detection via CRC and Error correction via Link level retry
