1-8
X10DRC/i-LN4+/-T4+ Motherboard User’s Manual
I/O Devices
SATA Connections
• SATA 3.0 Six (6) SATA 3.0 Ports support-
ed by Intel PCH (I-SATA 0-5),
Four (4) SATA 3.0 Ports support-
ed by Intel SCU (S-SATA 0-3)
• RAID 0, 1, 10 (from Intel PCH)
SAS Connections (for the X10DRC-LN4+/T4+)
• SAS 3.0 Eight (8) SAS Connections 0-3,
4-7 from the LSI 3108 controller
• RAID 0, 1, 5, 6, 10, 50, and 60 (from
the LSI SAS controller with
optional SuperCAP for battery
backup. See Note 1 next page.)
IPMI 2.0
• IPMI 2.0 supported by ASpeed AST 2400
Serial (COM) Port
• One (1) Fast UART 16550 Port
• One (1) Header
Peripheral
Devices
USB Devices
• Two (2) USB 2.0 ports (USB 0/1) and two (2) USB
3.0 ports (USB 4/5) on the I/O backpanel
• One (1) internal USB 2.0 header for two (2) USB
connections for front panel support (USB 2/3)
• One (1) internal USB 3.0 header for two (2) USB
connections for front panel support (USB 7/8)
• One (1) USB 3.0 Type A connector (USB 6)
BIOS
• 16 MB SPI AMI BIOS
®
SM Flash UEFI BIOS
• APCI 2.3, ACPI 2.0/3.0/4.0, USB Keyboard, Plug &
Play (PnP) and SMBIOS 2.3
Power
• ACPI Power Management
Management
• Main switch override mechanism
• Power-on mode for AC power recovery
• Intel
®
Intelligent Power Node Manager 3.0 (Avail-
able when the Supermicro Power Manager (SPM)
is installed and special power supply used. See
Page 1-14.)
• Management Engine (ME)
