Chapter 1: Overview

1-11

1-2 Processor and Chipset Overview

Built upon the functionality and capability of the Intel E5-2600v3 Series Proces-

sors (Socket R3) and the Intel C612 PCH, the X10DRC/i-LN4+/-T4+ motherboard

provides the best balanced solution of per formance, power efciency, and features

to address the diverse needs of next-generation data server platforms.

With support of new Intel Microarchitecture 22nm Process Technology, the

X10DRC/i-LN4+/-T4+ dramatically increases system performance for a multitude

of server applications.

The PCH C612 chip provides Enterprise SMbus and MCTP support, including the

following features:

•DDR4 288-pin memory support on Socket R3

•Support for MCTP Protocol and ME

•Support of SMBus speeds of up to 1 MHz for BMC connectivity

•Improved I/O capabilities to high-storage-capacity congurations

•SPI Enhancements

•Intel® Node Manager 3.0 support (See Note below.)

•BMC supports remote management, virtualization, and the security package

for enterprise platforms

Note: Node Manager 3.0 support is dependent on the power supply used

in the system.
