Chapter 1: Overview
1-7
Motherboard Features
CPU
• Dual Intel
®
E5-2600v3 Series Processors (Socket
R3-LGA 2011); each processor supports dual full-
width Intel QuickPath Interconnect (QPI) links (of up
to 9.6 GT/s one direction per QPI)
Note: Both CPU’s need to be installed for full
access the PCI-E slots and on-board con-
trollers. See the attached block diagram to
determine which PCI-E slots or devices may
be impacted.
Memory
• Integrated memory controller supports: up to 1536
GB of Load Reduced (LRDIMM) or up to 768 GB of
Registered (RDIMM) DDR4 (288-pin) ECC modules
2133/1866/1600 MHz in 24 slots
Note: Memory speed support is pending on
the CPUs used in the motherboard. For the
latest CPU/memory updates, please refer to
our website at http://www.supermicro.com/
products/motherboard.
DIMM sizes
• DIMM Up to 64 GB (per DIMM) @ 1.2V
Chipset
• Intel® PCH C612
Expansion
• Three (3) PCI Express 3.0 x8 slots (CPU2 Slot1/
Slot2/Slot6)
• Two (2) PCI-Express 3.0 x16 slots (CPU1 Slot3/
CPU2 Slot5)
• One (1) PCI-Express 2.0 x4 in x8 slot (CPU2 Slot4)
Slots
Graphics
• Graphics Controller via ASpeed AST 2400 BMC
Network
• Dual Intel i350 1GBASE-T (10/100/1000 Mb/s) Ether-
net controllers for GLAN1-GLAN4 ports (X10DRC/i-
LN4+), or
• Dual Intel X540 10GBASE-T (100/1000/10000
Mb/s) Ethernet controllers for TLAN1-TLAN4 ports
(X10DRC/i-T4+)
• ASpeed 2400 Baseboard Controller (BMC) supports
IPMI_LAN 2.0
