1-6
X10DRC/i-LN4+/-T4+ Motherboard User’s Manual
Note: Available on the X10DRC-LN4+/T4+ only.
Warning: To avoid damaging the power supply or the motherboard, be sure to use
a power supply that contains a 24-pin and two 8-pin power connectors. Be sure to
connect the power supply to the 24-pin power connector (J24), and two 8-pin power
connectors (JPWR1, JPWR2) on the motherboard. Failure in doing so may void the
manufacturer warranty on your power supply and motherboard.
(CPU2) Slot1 PCI-Express 3.0 x8 Slot from CPU2
(CPU2) Slot2 PCI-Express 3.0 x8 Slot from CPU2
(CPU1) Slot3 PCI-Express 3.0 x16 Slot from CPU1
(CPU2) Slot4 PCI-Express 2.0 x4 in x8 Slot from CPU2
(CPU2) Slot5 PCI-Express 3.0 x16 Slot from CPU2
(CPU2) Slot6 PCI-Express 3.0 x8 Slot from CPU2
S-SGPIO1,
T-SGPIO1/2
Serial_Link General Purpose I/O Headers 1/2/3 (for SATA ports),
(T-SGPIO1 for I-SATA0-3, T-SGPIO2 for I-SATA4/5, S-SGPIO1
for S-SATA0-3)
SP1 Internal Speaker/Buzzer
JSTBY1 +5V Standby Power Header
(BP) USB 0/1
(2.0)
Backpanel USB 2.0 Ports 0/1
(BP) USB 4/5
(3.0)
Backpanel USB 3.0 Ports 4/5
(FP) USB 7/8
(3.0)
Front Accessible USB 3.0 Connection Header 7/8
(FP) USB 2/3
(2.0)
Front Accessible USB 2.0 Connection Header 2/3
(FP) USB 6
(3.0)
Front Accessible USB 3.0 Connection Header 6
VGA Backpanel VGA Port
X10DRC/i-LN4+/-T4+ LED Indicators
LED Description State Status
DS13 (Note below) SAS Heartbeat LED Green: Blinking SAS Normal
LE1 Rear UID LED Blue: On Unit Identied
LE2 Onboard Power LED Green: On System PWR On
LEDM1 BMC Heartbeat LED Green: Blinking BMC Normal
LEDS5 (Note below) SAS Activity LED Green: Blinking SAS Active
LEDS6 (Note below) SAS Error LED Red: On SAS Error(s)
