Chapter 1: Overview
1-5
X10DRC/i-LN4+/-T4+ Jumpers
Jumper Description Default Setting
JBT1 Clear CMOS/Reset BIOS Conguration See Chapter 2
JI
2
C1/JI
2
C2 SMB to PCI-E Slots Pins 1-2 (Enabled)
JPB1 BMC Enable Pins 1-2 (Enabled)
JPG1 VGA Enable Pins 1-2 (Enabled)
JPLAN1 GLAN1/2 Enable (X10DRC/i-LN4+)
10G(T)_LAN1/2 Enable (X10DRC/i-T4+)
Pins 1-2 (Enabled)
JPLAN2 GLAN3/4 Enable (X10DRC/i-LN4+)
10G(T)_LAN3/4 Enable (X10DRC/i-T4+)
Pins 1-2 (Enabled)
JPME2 Manufacture (ME) Mode Select Pins 1-2 (Normal)
JPS1 SAS Enable Pins 1-2 (Enabled)
JWD1 Watch Dog Timer Enable Pins 1-2 (Reset)
X10DRC/i-LN4+/-T4+ Connectors
Connectors Description
Battery Onboard CMOS Battery (See Chpt. 3 for Used Battery Disposal)
(JBAT1)
COM1/COM2 Backplane COM Port1/Front Accessible COM2 Header
FAN1-6,
FANA-C
CPU/System Fan Headers
J24 24-pin ATX Main Power Connector (See Warning on Pg. 1-6.)
JD1 Speaker/Power LED
JF1 Front Panel Control Header
JIPMB1 4-pin External BMC I
2
C Header (for an IPMI Card)
JL1 Chassis Intrusion
JPI
2
C1 Power Supply SMBbus I
2
C Header
JPWR1/2 8-Pin Power Connectors
JSD1/JSD2 SATA DOM (Device on Module) Power Connectors
JTPM1 TPM (Trusted Platform Module)/Port 80 Header
JUIDB1 UID (Unit Identication) Button
LAN1/LAN2 Gigabit LAN(GLAN) Ethernet Ports 1/2 (X10DRC/i-LN4+)
10G(T) LAN Ethernet Ports 1/2 (X10DRC/i-T4+)
LAN3/LAN4 Gigabit LAN (GLAN) Ethernet Ports 3/4 (X10DRC/i-LN4+)
10G(T) LAN Ethernet Ports 3/4 (X10DRC/i-T4+)
(IPMI) LAN IPMI_Dedicated LAN support by the ASpeed controller
(I-)SATA 0-5 SATA 3.0 Connectors supported by Intel PCH (I-SATA 0-5)
(S-)SATA 0-3 SATA 3.0 Connectors supported by Intel SCU (S-SATA 0-3)
SAS0-3, 4-7
(3.0)
SAS 3.0 Connections supported by the LSI 3108 controller
(JS39) (for the X10DRC-LN4+/T4+ only)
