Preface
iii
Preface
This manual is written for system integrators, IT Professionals, and
knowledgeable end users. It provides information for the installation and use of the
X10DRC/i-LN4+/-T4+ motherboard.
About This Motherboard
The Super X10DRC/i-LN4+/-T4+ motherboard supports dual Intel E5-2600v3 Series
processors (Socket R3) that offer the new Intel Microarchitecture 22nm Processing
Technology, delivering the most-balanced solution of performance, power efciency,
and features to address the diverse needs of next-generation data centers. With the
PCH C612 built in, the X10DRC/i-LN4+/-T4+ motherboard supports MCTP Protocol,
and Intel® Node Manager 3.0. This motherboard is ideal for visualization, CRM,
storage, and general server platforms. Please refer to our website (http://www.
supermicro.com) for CPU and memory support updates.
Manual Organization
Chapter 1 describes the features, specications and performance of the moth-
erboard. It also provides detailed information about the Intel PCH C612 chipset.
Chapter 2 provides hardware installation instructions. Read this chapter when in-
stalling the processor, memory modules and other hardware components into the
system. If you encounter any problems, see Chapter 3, which describes trouble-
shooting procedures for video, memory, and system setup stored in the CMOS.
Chapter 4 includes an introduction to BIOS, and provides detailed information on
running the BIOS Setup utility.
Appendix A provides BIOS Error Beep Codes.
Appendix B lists Software Installation Instructions.
Appendix C contains UEFI BIOS Recovery instructions.
