Chapter 1: Overview
1-9
CPU
CPU Monitoring
Monitoring
• Onboard voltage monitoring for +3.3V, 3.3V Standby,
+5V, +5V Standby, +12V, CPU core, memory, chipset,
BMC, and battery voltages
• CPU/System overheat LED and control
• CPU Thermal Trip support
• Status Monitor for Speed Control
• Status Monitor for On/Off Control
• CPU Thermal Design Power (TDP): support up to
145W (See Note 2 below)
Fan Control
• Fan status monitoring via IPMI connections
• Dual Cooling Zone
• Low noise fan speed control
• Pulse Width Modulation (PWM) fan contorl
System
Management
• PECI (Platform Environment Conguration Interface)
2.0 support
• UID (Unit Identication)/Remote UID
• System resource alert via SuperDoctor 5
• SuperDoctor® 5, Watch Dog, NMI
• Chassis Intrusion Header and Detection
Dimensions
• 13.68" (L) x 13.05" (W) (347.47 mm x 331.47 mm)
Note 1: For SAS is supported by the onboard LSI3108 controller, and is
available on the X10DRC-LN4+/T4+ only)
Note 2: CPU Maximum Thermal Design Power (TDP) is subject to chassis
and heatsink cooling restrictions. For proper thermal management, please
check the chassis and heatsink specications for proper CPU TDP sizing.
Note 3: For IPMI Conguration Instructions, please refer to the Embedded
IPMI Conguration User's Guide available @ http://www.supermicro.com/
support/manuals/.
