IA3341 Linux User’s Manual Getting Started
2-2
Powering on the IA3341
Connect the SG wire to the shielded contact located in the upper left corner of the IA3341, and
then power on the computer by connecting it to the power adaptor. It takes about 30 to 60 seconds
for the system to boot up. Once the system is ready, the Ready LED will light up.
NOTE After connecting the IA3341 to the power supply, it will take about 30 to 60 seconds for the
operating system to boot up. The green Ready LED will not turn on until the operating system is
ready.
ATTENTION
This product is intended to be supplied by a Listed Power Unit and output marked with “LPS”
and rated 12-48 VDC, 580 mA (minimum requirements).
Connecting the IA3341 to a PC
There are two ways to connect the IA3341 to a PC: through the serial console port or by Telnet
over the network.
Serial Console
The serial console gives users a convenient way of connecting to the IA3341. This method is
particularly useful when using the computer for the first time. The serial console is useful for
connecting the IA3341 when you do not know either of the two IP addresses.
Use the serial console port settings shown below.
Baudrate
115200 bps
Parity
None
Data bits
8
Stop bit
1
Flow Control
None
Terminal
VT100
