IA3341 Linux User’s Manual Managing Communications
4-21
Step 6: Run the command “snmpd -c /etc/snmpd/snmpd.conf” to wake up snmp daemon.
192.168.3.127 – PuTTY
root@Moxa:/mnt/ramdisk/Net-SNMP# ./install.sh
Press the number:
1. Install Net-Snmp package
2. Uninstall Net-Snmp package
3. Exit.1
root@Moxa:/mnt/ramdisk#
Step 7: Use snmp-client to query from target for testing.
The following simple example allows you to use an snmpwalk program on the host site to query
the IA3341, which is the SNMP agent. The IA3341 will respond.
Uage like: snmpwalk –v 1 –c public TARGET IP .
***** SNMP QUERY STARTED *****
1: sysDescr.0 (octet string) Version 1.0
2: sysObjectID.0 (object identifier) enterprises.8691.12.240
3: sysUpTime.0 (timeticks) 0 days 03h:50m:11s.00th (1381100)
4: sysContact.0 (octet string) Moxa Systems Co., LDT.
5: sysName.0 (octet string) Moxa
6: sysLocation.0 (octet string) Unknown
7: sysServices.0 (integer) 6
8: ifNumber.0 (integer) 6
9: ifIndex.1 (integer) 1
10: ifIndex.2 (integer) 2
11: ifIndex.3 (integer) 3
12: ifIndex.4 (integer) 4
13: ifIndex.5 (integer) 5
14: ifIndex.6 (integer) 6
15: ifDescr.1 (octet string) eth0
16: ifDescr.2 (octet string) eth1
17: ifDescr.3 (octet string) Serial port 0
18: ifDescr.4 (octet string) Serial port 1
19: ifDescr.5 (octet string) Serial port 2
20: ifDescr.6 (octet string) Serial port 3
…
…
…
…
…
…
…
…
…
502: snmpInGenErrs.0 (counter) 0
503: snmpInTotalReqVars.0 (counter) 503
504: snmpInTotalSetVars.0 (counter) 0
505: snmpInGetRequests.0 (counter) 0
506: snmpInGetNexts.0 (counter) 506
507: snmpInSetRequests.0 (counter) 0
508: snmpInGetResponses.0 (counter) 0
509: snmpInTraps.0 (counter) 0
510: snmpOutTooBigs.0 (counter) 0
511: snmpOutNoSuchNames.0 (counter) 0
512: snmpOutBadValues.0 (counter) 0
513: snmpOutGenErrs.0 (counter) 0
