IA3341 Linux User’s Manual Managing Embedded Linux
3-4
3. Next, use the upfirm command to upgrade the kernel and root file system:
#upfirm IA3341-x.x.frm
192.168.3.127 – PuTTY
root@Moxa:/mnt/ramdisk# upfirm IA3341-1.0.frm
Moxa IA3341 upgrade firmware utility version 1.0.
To check source firmware file context.
The source firmware file conext is OK.
This step will destroy all your firmware.
Continue ? (Y/N) : Y
Now upgrade the file [kernel].
Format MTD device [/dev/mtd1] . . .
MTD device [/dev/mtd1] erase 128 Kibyte @ 1C0000 – 100% complete.
Wait to write file . . .
Compleleted 100%
Now upgrade the file [usrdisk].
Format MTD device [/dev/mtd2] . . .
MTD device [/dev/mtd2] erase 128 Kibyte @ 800000 – 100% complete.
Wait to write file . . .
Compleleted 100%
Upgrade the firmware is OK.
ATTENTION
The upfirm utility will reboot your target after the upgrade is OK.
Loading Factory Defaults
To load the the factory default settings, you must press the reset-to-default button for more than 5
seconds. All files in the /home and /etc directories will be destroyed. Note that while pressing the
reset-to-default button, the Ready LED will blink once every second for the first 5 seconds. The
Ready LED will turn off after 5 seconds, and the factory defaults will be loaded. In addition, you
can also use the command setdef for loading factory defaults. When finished, the system will
reboot and the factory defaults will be successfully loaded.
