IA3341 Linux User’s Manual Programmer’s Guide
6-2
Before Programming Your Embedded System
Caution Required when Using File Systems
We recommend that you only store your programs on the on-board NOR Flash. The log data
generated by your programs should be stored on an external storage device, such as an SD card or
Network File System. Note that a Network File System will generally provide the largest amount
of storage space. In addition, it is easier to replace a full or damaged SD card than an on-board
NOR Flash.
A NOR Flash has a life cycle of 100,000 write operations in the block (128 KB) level, but does not
support BBM (Bad Block Management). An SD card also has a life cycle, but most SD cards are
made from a NAND Flash, for which the hardware controllers implement BBM. This feature
allows FAT to skip bad blocks if they exist. Furthermore, the memory space of an SD card is much
larger than that of the NOR Flash. Cautiously utilizing this space will ensure that its life cycle will
not be exceeded. When creating a file for storing log data, we suggest setting up your program to
create a large empty file (e.g., 30 MB), and then write data evenly over the space. When reaching
the end of the space, the program rewinds the write operations. As a result, the number of write
operations on each block will be reduced.
Using a RAM File System instead of a Flash File System
Although data in the RAM file system will be wiped out after a power off, this file system has
several advantages over a Flash file system. The RAM file system includes faster read/write access,
and has no life cycle issues.
For timely and/or important applications that relay data directly back to the host, you should write
the necessary log data to the RAM file system. After the host accesses the data, the application will
erase the data to free up the space for further uses.
The embedded computer has limited resources, and for this reason, designers should determine if
storing data in a file system is really necessary. If it is necessary, then be sure to choose the most
appropriate file system for your application.
Flash Memory Map
Partition sizes are hard coded into the kernel binary. To change the partition sizes, you will need to
rebuild the kernel. The flash memory map is shown in the following table.
Address Size Contents
0x00000000 – 0x0003FFFF 256 KB Boot Loader—Read ONLY
0x00040000 – 0x001FFFFF 1.8 MB Kernel object code—Read ONLY
0x00200000 – 0x009FFFFF 8 MB Root file system (JFFS2) —Read ONLY
0x00A00000 – 0x00FFFFFF 6 MB User directory (JFFS2) —Read/Write
Device API
The IA3341 supports control devices with the ioctl system API. You will need to
include
<moxadevice.h>
, and use the following ioctl function.
int ioctl(int d, int request,…);
Input: int d - open device node return file handle
int request – argument in or out
Use the desktop Linux’s man page for detailed documentation:
#man ioctl
