IA3341 Linux User’s Manual Managing Communications
4-19
Installing Net-SNMP
The IA3341 supports the Net-SNMP daemon. However, it has not been included in the default
value, so you need to install it manually if you need to use this function. Make sure you have
enough memory space available to install Net-SNMp, which will occupy about 3 MB on your
embedded flash ROM. The IA3341 has the SNMP V1 (Simple Network Management Protocol)
agent software built in. SNMP V1 supports RFC1317 RS-232 like groups and RFC 1213 MIB-II.
Step 1: Check to make sure you have enough memory space.
192.168.3.127 - Putty
root@Moxa:~#
root@Moxa:~# df –h
Filesystem Size Used Available Use% Mounted on
/dev/root 8.0M 5.7M 2.3M 71% /
/dev/ram3 1003.0K 9.0K 943.0K 1% /dev
/dev/ram0 499.0K 18.0K 456.0K 4% /var
/dev/mtdblock3 6.0M 492.0K 5.5M 8% /tmp
/dev/mtdblock3 6.0M 492.0K 5.5M 8% /home
/dev/mtdblock3 6.0M 492.0K 5.5M 8% /etc
tmpfs 30.5M 0 30.5M 0% /dev/shm
root@Moxa:~#
Check that /dev/mtdblock3 has more than 3.5 MB of free space.
Step 2: Type upramdisk to get the free space ram disk to save the package.
192.168.3.127 - Putty
root@Moxa:~# upramdisk
root@Moxa:~# df –h
Filesystem Size Used Available Use% Mounted on
/dev/root 8.0M 5.7M 2.3M 71% /
/dev/ram3 1003.0K 9.0K 943.0K 1% /dev
/dev/ram0 499.0K 18.0K 456.0K 4% /var
/dev/mtdblock 3 6.0M 492.0K 5.5M 8% /tmp
/dev/mtdblock 3 6.0M 492.0K 5.5M 8% /home
/dev/mtdblock 3 6.0M 492.0K 5.5M 8% /etc
tmpfs 30.5M 0 30.5M 0% /dev/shm
/dev/ram1 16.0M 1.0K 15.1M 0% /var/ramdisk
root@Moxa:~#
Step 3: Download the Net-SNMP package from the CD-ROM. You can find the package in
CD-ROM/target/net-snmp/Net-SNMP.tar.gz
192.168.3.127 – PuTTY
root@Moxa:/bin# cd /mnt/ramdisk
root@Moxa:/mnt/ramdisk# ftp 192.168.27.130
Connected to 192.168.27.130.
220 (vsFTPd 2.0.1)
Name (192.168.27.130:root): root
331 Please specify the password.
Password:
230 Login successful.
