Moxa IA3341-LX [11/72] Windows users

IA3341 Linux User’s Manual Getting Started

2-3

Once the connection is established, the following window will open.

ATTENTION

Serial Console Reminder

Remember to choose VT100 as the terminal type. Use the cable CBL-4PINDB9F-100, which

comes with the IA3341, to connect to the serial console port.

SSH Console

The IA3341 supports an SSH Console to provide users with better security options.

Windows Users

Click on the link http://www.chiark.greenend.org.uk/~sgtatham/putty/download.html to download

PuTTY (free software) to set up an SSH console for the IA3341 in a Windows environment. The

following figure shows a simple example of the configuration that is required.
