IA3341 Linux User’s Manual Managing Communications

4-22

514: snmpOutGetRequests.0 (counter) 0

515: snmpOutGetNexts.0 (counter) 0

516: snmpOutSetRequests.0 (counter) 0

517: snmpOutGetResponses.0 (counter) 517

518: snmpOutTraps.0 (counter) 0

519: snmpEnableAuthenTraps.0 (integer) disabled(2)

***** SNMP QUERY FINISHED *****

NOTE Click on the following links for more information about MIB II and RS-232 like groups:

http://www.faqs.org/rfcs/rfc1

213.html

http://www.faqs.org/rfcs/rfc1

317.html

The IA3341 does NOT support SNMP trap.
