V2616A Linux Managing Communications
3-26
2. The configuration procedure is almost the same as for the previous example. The only difference is that you
will need to comment out the parameter up in /etc/openvpn/tap0-br.conf of OpenVPN A and
/etc/openvpn/tap0-br.conf of OpenVPN B.
# point to the peer
remote 192.168.8.174
dev tap0
secret /etc/openvpn/secrouter.key
cipher DES-EDE3-CBC
auth MD5
tun-mtu 1500
tun-mtu-extra 64
ping 40
#up /etc/openvpn/tap0-br.sh
#comp-lzo
Routed IP
1. Set up four machines, as shown in the following diagram.
2. On machine OpenVPN A, modify the remote address in configuration file /etc/openvpn/tun.conf.
# point to the peer
remote 192.168.8.174
dev tun
secret /etc/openvpn/secrouter.key
cipher DES-EDE3-CBC
auth MD5
tun-mtu 1500
tun-mtu-extra 64
ping 40
ifconfig 192.168.2.173 192.168.4.174
up /etc/openvpn/tun.sh
-----
3. Next, modify the routing table in script file /etc/openvpn/tun.sh.
#---------------------------Start----------------------------
#!/bin/sh
# value after “-net” is the subnet behind the remote peer
route add -net 192.168.2.0 netmask 255.255.255.0 gw $5
#----------------------------end-----------------------------
